- SKU:
- 3600400060
Description
Fronius Grid Transfer Switch
The scope of delivery includes cable glands and a Fronius Smart Meter (TS65A-3).
This box features all-pole disconnection for TN-S/TT grids. It is not suitable for TN-C grids!
Approved battery inverters:
Fronius Symo Gen24 6.0 Plus/8.0 Plus/10.0 Plus
Fronius Symo Hybrid 3.0-3-S/4.0-3-S/5.0-3-S
Max. thermal through power: 20 kW
Country approval: Germany/Austria*/Switzerland
*Note: Some Austrian grid operators require FRT capability for the transfer device.
A transfer switch box with FRT capability for Austria can be requested from us and ordered for you on a per-order basis.
Please check the respective grid operator requirements before ordering.
*Due to material shortages, the transfer switch box is supplied in two variants.
The products differ only in appearance and housing dimensions.
The technical function remains the same, as do the wiring and connections.
(please refer to the new datasheet)
Product information
| Inverter-type | Accessories |
|---|---|
| Dimensions | Variante 1: 340x622x161 mm // Variante 2: (BxHxT): 315x600x155 mm |
| Manufacturer´s product warranty | 2 Years |
| Herstellerlink | https://www.fronius.com/de-de/germany |
