AC rated power: 5 000 W | Max. DC input current per string: 16 A | Phases: 1 | Number of MPP trackers: 2 | Dimensions: 540 x 350 x 395 mm | Scope of delivery: Hybrid inverter (power control unit) & energy meter incl. 3x CT current transformers | 10-year manufacturer warranty | Zerez ID: FH3X-5K-HY-1P-5: ZE-B50T-J8WJ-0002
FH3X-5K-HY-1P-10: ZE-B50T-J8WJ-0006
FH3X-5K-HY-1P-15: ZE-B50T-J8WJ-0010
FH3X-5K-HY-1P-20: ZE-B50T-J8WJ-0014
- SKU:
- FH3X5K-HY-1PEU
€1,637.00
Incl. 0% VAT
Description
Pylontech Force H3X 5.0 kW Hybrid Inverter
The Force H3X hybrid is a modular high-voltage inverter designed to be combined with the Pylontech Force H3 5.12 kWh high-voltage battery module. Ideal for energy storage applications in residential buildings and small commercial businesses.
This unit is ideal for single- and multi-family homes, commercial applications and larger PV storage projects that require an integrated solution with battery, smart energy management functions and high system stability.
Please note that this product includes only the Force H3X hybrid inverter for the all-in-one system. The base plate is included with the inverter. Please combine the inverter with the Pylontech Force H3 5.12 kWh modules.
Compatible with 1–4 battery modules.
Product advantages:
- Modular design: Stackable battery modules for flexible capacity expansion
- High voltage: Efficient energy conversion and reduced cable losses
- Intelligent BMS: The advanced battery management system ensures safety and performance
- Easy installation: Plug-and-play design with minimal wiring effort, 15-minute installation and commissioning time
- IP55 for outdoor installation
Zerez ID (VDE-AR-N 4105 / LV):
- FH3X-5K-HY-1P-5: ZE-B50T-J8WJ-0002
- FH3X-5K-HY-1P-10: ZE-B50T-J8WJ-0006
- FH3X-5K-HY-1P-15: ZE-B50T-J8WJ-0010
- FH3X-5K-HY-1P-20: ZE-B50T-J8WJ-0014
Product information
| Inverter-type | Hybrid Inverter |
|---|---|
| Phases | 1-Phase |
| Max. Output Power (kW) | 5,0 |
| MPP trackers | 2 |
| Input voltage range (V) | 80-550 |
| Input current per MPP-Tracker (A) | 16 |
| Short-Circuit current per MPP-Tracker (A) | 25 |
| Backup/Emergency power capable | Yes |
| Integrated DC surge protection | Yes |
| Dimensions | 540 x 350 x 395 mm |
| Manufacturer´s product warranty | 10 Years |
| Herstellerlink | https://www.pylontech.de |
Delivery
| Germany | Delivery time is about 2 to 10 working days. |
|---|---|
| EU Country | Delivery time is about 5 to 15 working days. |
