AC rated power: 8 500 / 10 000 / 12 500 W (depending on power class) | Max. DC input current per string: 17 A | Phases: 3 | Number of MPP trackers: 3 | Dimensions: 561 x 409 x 237 mm | Scope of delivery: Inverter | 5-year manufacturer warranty | Zerez ID: 8,5kW ZE-03XE-O8OD-0004; 10kW ZE-03XE-O8OD-0005; 12,5kW ZE-03XE-O8OD-0006
- SKU:
- 10543198
€1,799.00
Incl. 0% VAT
Description
Kostal Plenticore G3 S 8.5–12.5 kW Hybrid Inverter
The battery activation code is unlocked with 3 Plenticoins.
Can be expanded with Plenticoins. With 1 Plenticoin to 10.0 kW and with 2 Plenticoins to 12.5 kW – maximum upgrade up to 12.5 kW.
Product advantages:
- All-in-one
- Smart performance
- Smart connected
- Installer-friendly
Product information
| Inverter-type | Hybrid Inverter |
|---|---|
| Phases | 3-Phase |
| Max. Output Power (kW) | 8,5 |
| MPP trackers | 3 |
| Input voltage range (V) | 75-900 |
| Input current per MPP-Tracker (A) | 2x17,0 / 1x30,0 |
| Short-Circuit current per MPP-Tracker (A) | 2x23,8 / 1x42,0 |
| Backup/Emergency power capable | with accessories |
| Integrated DC surge protection | No |
| Zerez ID (VDE-AR-N 4105 / NS) | 8,5kW ZE-03XE-O8OD-0004; 10kW ZE-03XE-O8OD-0005; 12,5kW ZE-03XE-O8OD-0006 |
| Dimensions | 561 x 409 x 237 mm |
| Manufacturer´s product warranty | 5 Years |
| Manufacturer link | http://www.kostal-plenticore.com/ |
Delivery
| Germany | Delivery time is about 2 to 10 working days. |
|---|---|
| EU Country | Delivery time is about 5 to 15 working days. |
